Tuchel-Trac MINI 2


Small – Compact – Flexible!

With this vehicle miracle you can manage many jobs around your farm easy and quick.
The TUCHEL-TRAC MINI 2 convinces by its comfortable getting on and dismounting from the vehicle, small turn radius and a quick-hitch, which provides a tool-less and user-friendly mounting and dismounting of many attachments.
Simply select from the two versions “MINI 2 M” or “MINI 2 H”.




MINI 2 M:

  • Briggs & Stratton Series 950E, 1-cylinder air-cooled petrol engine
  • E-Starter and reversing starter
  • 4,9 kW (6,6 HP / 3600 rpm)
  • Hydrostatic front wheel drive by V-belt
  • Forward: 6,3 km/h, backwards: 5,5 km/h
  • Parking brake operated via hand lever
  • Mechanical steering via steering rod
  • Turn radius 490 mm (inner)
  • Three pneumatic tyres (field tyres)
  • Guard bracket for the rear wheel
  • Mechanical lifting-device incl. quick-hitch
  • Hour meter
  • Splash-proof ignition lock

MINI 2 H – same equipment as MINI 2 M, but with:

  • Honda GXV 340, 1-cylinder air-cooled petrol engine
  • 6,6 kW (9 HP / 3600 rpm)
  • Forward: 6,3 km/h, backwards: 5,5 km/h
  • One double-acting hydraulic drive circuit
  • Hydraulic lifting-device incl. quick-hitch
  • Single-acting lifting unit in floating position for levelling
  • Working hydraulic: 9,8 l/min at 180 bar
  • 16,5 liters Hydraulic tank/li>



Each machine can be configurated individually according to your requirements.
For further technical details and equipment, please refer to the leaflet.
